1UP Racing 1/28 Titanium Geared Digital Micro Servo (HV)
About this part
Servo Overview:
Take your 1/28 racing to the next level with the 1UP Racing Precision Aluminum Micro Servo, a precision-engineered digital servo built for ultimate steering control, speed, and durability.
About the Precision Aluminum Micro Servo
Precision Racing Control
The 1UP Racing Precision Aluminum Micro Servo is purpose-built for serious 1/28 racers, featuring a high-performance coreless motor and precision geartrain with a titanium main gear for quick, accurate steering response. With response speeds as fast as 0.052 sec/60° at 8.4V and a 20T titanium output spline, it delivers the speed and control needed for competitive racing.
Durable Compact Design
Housed in a fully CNC-machined aluminum case for increased strength and improved heat dissipation, the Precision Aluminum Micro Servo delivers serious performance in an incredibly compact 20 x 8 x 17.8mm footprint. Its lightweight 7g construction and wide 4.8–8.4V operating range make it ideal for space-conscious 1/28 builds, while the 20T output spline provides compatibility with a wide range of steering components and chassis platforms.
Features:
- Ultra-fast response of 0.052 sec/60° at 8.4V
- Ultra-fast steering response
- High-performance coreless motor
- Precision geartrain with titanium main gear
- CNC-machined aluminum case
- 20T titanium output spline
- High-voltage 8.4V compatibility
- Compact 8mm-wide design
- Ultra-lightweight 7g construction
- Ideal for competitive 1/28 scale applications
Includes:
- 1UP Racing Precision Aluminum Micro Servo
Specifications:
| Application | 1/28 Scale |
|---|---|
| Input Voltage | 4.8-8.4V |
| Operating Speed @ 4.8V | 0.075 sec/60° |
| Operating Speed @ 6.0V | 0.066 sec/60° |
| Operating Speed @ 7.4V | 0.058 sec/60° |
| Operating Speed @ 8.4V | 0.052 sec/60° |
| Stall Torque @ 4.8V | 25oz-in (1.8kg-cm) |
| Stall Torque @ 6.0V | 30oz-in (2.2kg-cm) |
| Stall Torque @ 7.4V | 36oz-in (2.6kg-cm) |
| Stall Torque @ 8.4V | 41oz-in (3.0kg-cm) |
| Motor Type | Coreless |
| Gear Material | Metal & Titanium |
| Output Shaft Spline | 20T |
| Connector | Micro JST |
| Dimensions | 0.79x0.31x0.70in (20x8x17.8mm) |
| Weight | 0.25oz (7g) |
