Name: EMAX Tinyhawk II Parts Runcam Nano 2 Replacement w/ Plug
Brand: EMAX
SKU: EMX-708111880800
Price: 19.99 USD

EMAX Tinyhawk II Parts Runcam Nano 2 Replacement w/ Plug

AMain Hobbies

Tinyhawk 2

<div>The replacement EMAX Tinyhawk II Parts Runcam Nano 2 with Plug is one of the world's smallest and best WDR racing cameras. It's 14x14mm dimensions mean its a "nano" size - smaller than a micro camera, so keep that in mind when thinking about mounting options.
</div>
<div>
  <br>
</div>
<div><strong>Specifications:</strong>
</div>
<div><strong>Model: </strong>RunCam Nano 2
</div>
<div><strong>Image Sensor:</strong> 1/3" CMOS
</div>
<div><strong>Horizontal Resolution:</strong> 700TVL
</div>
<div><strong>Lens:</strong> 2.1mm(M8) FOV 155° 1.8mm (M8) FOV 170°
</div>
<div><strong>Signal System:</strong> PAL/NTSC Non-Switchable
</div>
<div><strong>S/N Ratio:</strong> &gt;50dB
</div>
<div><strong>Electronic Shutter Speed:</strong> Auto
</div>
<div><strong>Auto Gain Control (AGC):</strong> Auto
</div>
<div><strong>Min. Illumination:</strong> 0.01Lux@1.2F
</div>
<div><strong>D-WDR:</strong> Auto
</div>
<div><strong>Day/Night:</strong> Color
</div>
<div><strong>Power:</strong> DC 3-5.5V
</div>
<div><strong>Current:</strong> 110mA@5V 120mA@3.3V
</div>
<div><strong>Housing Material:</strong> ABS
</div>
<div><strong>Net Weight: </strong>3.2g
</div>
<div><strong>Dimensions:</strong> L14mm*W14mm*H16mm
</div>
<div>
  <br>
</div>

The replacement EMAX Tinyhawk II Parts Runcam Nano 2 with Plug is one of the world's smallest and best WDR racing cameras. It's 14x14mm dimensions mean its a "nano" size - smaller than a micro camera, so keep that in mind when thinking about mounting options. Specifications: Model: RunCam Nano 2 Image Sensor: 1/3" CMOS Horizontal Resolution: 700TVL Lens: 2.1mm(M8) FOV 155° 1.8mm (M8) FOV 170° Signal System: PAL/NTSC Non-Switchable S/N Ratio: &gt;50dB Electronic Shutter Speed: Auto Auto Gain Control (AGC): Auto Min. Illumination: 0.01Lux@1.2F D-WDR: Auto Day/Night: Color Power: DC 3-5.5V Current: 110mA@5V 120mA@3.3V Housing Material: ABS Net Weight: 3.2g Dimensions: L14mm*W14mm*H16mm
