Junsi iCharger DX6 DC Dual LiPo/Life/NiMH/NiCD Battery Charger (6S/50A/1500W)
About this part
iCharger DX6 Overview:
The Junsi iCharger DX6 DC Battery Charger is a high power charger that is capable of charging at up to 1500 watts. Using extreme accuracy, this charger features different balance modes keeping your LiPo batteries fresh and performing at their best. The charger shares the accessible and easy-to-understand user interface found in the other popular Junsi iChargers. Experience supreme quality and unmatched charging performance with the Junsi DX6 charger!
Features:
- Advanced Synchronous buck-boost DC/DC converter technology, high power, a high current and high-performance power conversion circuit.
- Each channel supports up to 6S LiPo, Lilo, LiFe, LiHV, LTO and NiZn batteries
- Digital-power mode for great protection
- Internal temperature protection
- Can save 64 parameter sets and support the data import/export to SD card
- Full color 2.4" IPS LCD screen
- Multi-discharge features such as Self-discharge
Specifications:
- Dimension (LxWxH): 112×92×40mm
- weight: 360g
- Input Voltage: 9—34VDC
- Maximum Input Current Limit:: 65A
- Maximum Charge/Discharge Current: 35A x2 (50A Bridged)
- Maximum charge Power Capacity: 900W x2 (1600W Bridged)
- Maximum Discharge Power Capacity: 46W x2 (60W Bridged)
- Maximum Regenerative Discharge Power Capacity: 900W x2 (1500W Bridged)
- Maximum Extra Discharge Power Capacity: 900W @30V/32A (1600W Bridged)
- Support Battery Type: LiPo, Lilo, LiFe, LiVH, LTO, NiZn, NiMH, NiCd, Pb
Includes:
- (1) iCharger DX6 DC Dual Battery Charger
Reviews4.7 · 13 reviews
Make sure to order cables or the charger will be useless to you when it arrives other than that works great.should say it doesn't come with them in add.
Top notch charger………..……… would recommend………………………..
I am having problems with my new icharger dx6 duo keep giving errors in middle of charging 2s 460mah batteries I changed charging cables Updated firmware to 1.17 Ordered new batteries because I thought maybe my batteries are no good Results are the same and I noticed my IR reading are inconsistent and keep jumping super high sometimes in 60 while batteries are new I doubted myself so I went to my old charger and tried same batteries and same cables and noticed nothing wrong with my batteries or cable. It’s the charger Contacted customer service and got no response sadly Edit: google recommended to clean the balance terminals on the charger with alcohol and update to firmware 1.19 And seems like have solved the problem At the mean time Still never heard back from customer service here at Amain
As an avid RC enthusiast, I've had the chance to put the DX6 LiPo battery charger through its paces, and overall, it's proven to be a reliable addition to my toolkit. One of the standout features is its intuitive interface, which makes it quite user-friendly, even for beginners. The display is clear and provides all the essential information, like charging status and voltage levels, at a glance. I appreciate the safety features, such as overcharge protection, which give me peace of mind while charging my batteries. The build quality is robust, and it's compact enough to easily transport to race tracks. For anyone seeking a dependable charger for their LiPo batteries, the DX6 is a solid choice that balances functionality and ease of use effectively.
I really like this charger the only reason I didn’t give it a 5 star is that it don’t come with any leads or the x 90 connector it needs other than that it is awesome and I would highly recommend it
Reviewers largely rate the Junsi iCharger DX6 highly, praising its accurate balancing, high output, compact size, quiet operation and dual-channel charging. Several note the menu is not intuitive at first but becomes manageable after reading the manual. A recurring issue is that charging cables and the X90 connector are not included, so buyers must purchase them separately. One reviewer reported intermittent errors mid-charge and inconsistent internal resistance readings on small 2S packs, which they attributed to the charger after swapping cables and batteries; a firmware update and cleaning the balance terminals were suggested, and their support contact went unanswered. Other reviewers reported no such problems.
- + Accurate, balanced charging
- + Compact and lightweight
- + Quiet operation
- + Charges two batteries at once
- − Cables and X90 connector not included
- − Menu navigation less intuitive initially
- − One report of mid-charge errors and inconsistent IR readings
