Maverick FLX10-3S100 Flux 1/10 Brushless ESC

ESC Overview:

Maverick FLX10-3S100 Flux 1/10 Brushless ESC. This is a replacement ESC intended for use on the Maverick Quantum+ XT Flux 1/10 3S 4WD Brushless vehicles. This can also work with other 1/10 applications that require a 100 amp continuous current. Manufactured by HPI Racing, a brand known for its durable and high-performance components, this ESC is no exception to the attention to detail and efficiency that HPI provides. This ESC offers a blend of power with user-friendly features such as the programmable settings that can be adjusted to optimize performance on various types of vehicles. It is designed to work with 2S to 3S batteries, allowing for flexible voltage inputs from 7.4V to 11.1V.

Features:

• Users can fine-tune parameters such as throttle response, braking power, and motor timing
• Equipped with an efficient cooling system, including a heatsink and a cooling fan
• Built with high-quality components and a durable design
• Designed to be water resistant and dustproof, enhancing its reliability in various environments
• Pre-soldered connectors and user-friendly instructions
• Uses 2S to 3S LiPo batteries, allowing a wide range of voltage inputs (7.4V-11.1V)
• Compatible with HPI Flux Reload Program Box V3 (HPI160014) sold separately for easy programming
• Capable of handling up to 100 amps of continuous current
• Designed for the Flux series, but is compatible with various on-road and off-road vehicles

Specifications:

• Suggested Application: 1/10
• Motor Type: Brushless-Sensorless
• Input Voltage: 2-3S LiPo
• Continuous Current: 100A
• Burst Current: 650A
• Dimensions: 1.93x1.54x1.37in (49x39.5x34.7mm)
• Weight: 3.7oz (105g)
• Motor Limits:
  • 2S LiPo: 5500kV
  • 3S LiPo: 3500kV
• BEC Voltage: 6V-7.4V
• BEC Continuous Current: 3A
• BEC Peak Current: -
• Motor Connector: 4.0mm Bullet
• Battery Connector: T-Plug
• Motor Wire: 12AWG
• Battery Wire: 12AWG
• Throttle Wire: -
• Programmable: Yes

Includes:

• (1) Maverick FLX10-3S100 Flux 1/10 Brushless ESC
• Product Manual
