Parts/Radio & control/Servos/MKS Servos HV1220 Titanium Gear Ultra High Torque Standard Digital Servo (High Voltage)
About this part
This is the MKS HV1220 Titanium Gear Ultra High Torque Standard Digital Servo. This high torque servo was developed for high voltage applications and is a great choice for 1/8 and 1/10 Scale Buggies, Monster Trucks and Rock Crawlers, Giant Scale Aircraft, and 600~700 CCPM heli applications.
Specifications:
Specifications:
- Torque:
- @6.0V: 230 oz-in (16.6 kg-cm)
- @6.8V: 281.9 oz-in (20.3 kg-cm)
- @8.2V: 319.4 oz-in (23 kg-cm)
- Speed:
- @6.0V: 0.159 s
- @6.8V: 0.140 s
- @8.2V: 0.115 s
- Weight: 57.64 g
- Dimensions: 40x20x37mm
- Operating Voltage: 6.0 ~ 8.2 V DC Volts
- Working Frequency: 1520?s / 333hz
- Dead Band: 0.0008ms (Default)
- Bearing Type: 2BB
- Motor Type: Japan High Quality Coreless Motor
- Gear Type: Chrome-Titanium alloy gear
Reviews1.0 · 1 review
Jaffray StephensonVerified owneron MKS Servos HV1220 Titanium Gear Ultra High Torque Standard Digital Servo (High Voltage)
The servos were dead on arrival...and since AMain does not handle the warranty, I had to send them to MKS directly, who, by the way, were very helpful. I'll let you know what I think when I get a pair that actually work.
Builds using this part
No builds use this part yet — add it to yours from the build editor.
