About this part
- Uses Pulse Width Control (PWM)
- Japanese High Quality Brushless Motor
- 8mm 25tooth X8
- Great for large scale airplanes, jets, helicopter cyclic or surface vehicles
- Voltage: 5-8.4 Volts
- Torque:
- 6V: 583.2 oz/in (42 kg/cm)
- 7.4V: 708.2 oz/in (51 kg/cm)
- 8.4V: 791.5 oz/in (57 kg/cm)
- Speed:
- 6V: 0.142 sec/60°
- 7.4V: 0.115 sec/60°
- 8.4V: 0.104 sec/60°
- Current Draw:
- 6V: 5.8A
- 7.4V: 7.4A
- 8.4V: 8.2A
- Dimensions: 40x20x38.5mm
- Weight: 74g (2.61 oz)
- Working Frequency: 1520us / 333Hz
- Dead Band: 0.0008ms (Default)
- Temperature Range: -10 to + 60 Degree C
- Bearing: 12x8mm Double bearings
- Gear: Metal Alloy Gear
